ATI443S3 ATI Microstop Cage

Price: Price On Request

Part Number: ATI443S3

ATI443S3 ATI Microstop Cage. Depth Adjustment: .0005” Cutter Capacity: 3/4” Shaft Travel: 5/16” Spindle Thread: 1/4-28 Female Max RPM: 3000 Skirt Type: Straight Shaft Shank: Quick Change

ATI443S3 ATI Microstop Cage Description

The ATI443S3 ATI Microstop Cage is an expertly crafted tool built for light to medium-duty production environments, capable of operating at speeds up to 3,000 RPM. With a bronze bushing for optimal shaft support and a heavy-duty ball thrust bearing, it ensures exceptional depth repeatability, making it ideal for precision machining.

The fail-safe design, featuring an integrated shoulder on the shaft, provides additional security, while the right-hand threaded lock nut prevents jamming in the adjustment mechanism. Durable and reliable, the ATI443S3 ATI Microstop Cage guarantees consistent, high-quality performance in demanding applications, ensuring long-term accuracy and ease of use.

Made In The USA

Technical Specifications

Additional information

Depth Adjustment

.0005''

Cutter Capacity

3/4''

Shaft Travel

5/16''

Spindle Thread

1/4-28 Female

Max RPM

3000

Skirt Type

Straight

Shaft Shank

Quick Change

ATI443S3 ATI Microstop Cage

The ATI443S3 ATI Microstop Cage is an expertly crafted tool built for light to medium-duty production environments, capable of operating at speeds up to 3,000 RPM. With a bronze bushing for optimal shaft support and a heavy-duty ball thrust bearing, it ensures exceptional depth repeatability, making it ideal for precision machining.

The fail-safe design, featuring an integrated shoulder on the shaft, provides additional security, while the right-hand threaded lock nut prevents jamming in the adjustment mechanism. Durable and reliable, the ATI443S3 ATI Microstop Cage guarantees consistent, high-quality performance in demanding applications, ensuring long-term accuracy and ease of use.

Made In The USA

Additional information

Depth Adjustment

.0005''

Cutter Capacity

3/4''

Shaft Travel

5/16''

Spindle Thread

1/4-28 Female

Max RPM

3000

Skirt Type

Straight

Shaft Shank

Quick Change
