ATP1520EI-TH ATP Grip Handle Impact Wrench, 1-1/2” Square Drive. Drive Type: Square Working Torque: 2500 ft-lbs / 3400 Nm Max Torque: 3000 ft-lbs / 4067 Nm Tool Duty Rating: Super Duty Handle Type: Grip Throttle Type: Inside Trigger Drive Size: 1-1/2”
The ATP1520EI-TH ATP Grip Handle Impact Wrench, 1-1/2” Square Drive is engineered for both power and versatility, making it an excellent choice for a wide range of applications. Featuring a two-jaw clutch, it efficiently transfers high power, providing robust performance for demanding tasks. Its three-piece housing design allows for easy repair and maintenance, ensuring long-term reliability.
The steel clutch housing offers exceptional durability, making it suitable for both hard and soft draw applications. Additionally, the integral muffler effectively reduces noise, creating a more comfortable working environment. The ATP1520EI-TH ATP Grip Handle Impact Wrench, 1-1/2” Square Drive is perfect for professionals who require a dependable and high-performing tool in various industrial settings.
| Drive Type | Square |
|---|---|
| Working Torque | 2500 ft-lbs / 3400 Nm |
| Max Torque | 3000 ft-lbs / 4067 Nm |
| Tool Duty Rating | Super Duty |
| Handle Type | Grip |
| Throttle Type | Inside Trigger |
| Drive Size | 1-1/2'' |
| Impact Mechanism / Clutch | Two Jaw |
| Socket Retainer | Through Hole |
| Housing Construction | 3 Piece |
| Length | 14.70'' / 373mm |
| Weight | 33lbs / 14.90kg |
| Air Inlet NPT | 1/2'' |
| Min Hose ID | 3/4'' / 19mm |
| Performance Pressure | 90 PSIG / 6.2 Bar |
| Air Consumption | 70 cfm / 1, 982 l/min |
| OEM | Chicago Pneumatic |
| Comparable OEM Model | CP6120-PASED |
