CP0200B18 Chicago Pneumatic Bench Rammer. Part Number: 615 161 8010 Blows Per Minute: 1,800BPM Power: 5.6joule Bore: 0.7” / 18mm Stroke: 2” / 50mm Butt Diameter: 1.61” / 41mm Length: 11.0” / 280mm Weight: 3.3lb / 1.5kg
CP0200B18 Chicago Pneumatic Bench Rammer The CP0200B18 Chicago Pneumatic Bench Rammer is designed to be compact and lightweight with a high efficiency due to the high BPM. This sand rammer features extra durability due to heat treated parts available in 0.7” (18mm) / 1” (25.4mm). The CP0200B18 Chicago Pneumatic Bench Rammer is ideal for foundry applications with comfortable operation/high production. This sand rammer should be used for casting sand in cylinders and large molds.
| Model Number | CP0200B18 |
|---|---|
| Part Number | 615 161 8010 |
| Blows Per Minute | 1, 800BPM |
| Power | 5.6joule |
| Bore | 0.7'' / 18mm |
| Stroke | 2'' / 50mm |
| Butt Diameter | 1.61'' / 41mm |
| Length | 11.0'' / 280mm |
| Weight | 3.3lb / 1.5kg |
| Air Cons. at Load | 14.1cfm / 6.7l/s |
| Air Inlet | 1/4'' |
| Inner Hose DIA. | 3/8'' / 10mm |
| Sound Press/Power | 95 / 106 ISO 15744-dB(A) |
| Vibration Level | ISO 28927(M/S2) 19.4a / 5.9k |
| Model Number | CP0200B18 |
|---|---|
| Part Number | 615 161 8010 |
| Blows Per Minute | 1, 800BPM |
| Power | 5.6joule |
| Bore | 0.7'' / 18mm |
| Stroke | 2'' / 50mm |
| Butt Diameter | 1.61'' / 41mm |
| Length | 11.0'' / 280mm |
| Weight | 3.3lb / 1.5kg |
| Air Cons. at Load | 14.1cfm / 6.7l/s |
| Air Inlet | 1/4'' |
| Inner Hose DIA. | 3/8'' / 10mm |
| Sound Press/Power | 95 / 106 ISO 15744-dB(A) |
| Vibration Level | ISO 28927(M/S2) 19.4a / 5.9k |
Discontinued
Discontinued
Discontinued
