Ingersoll Rand 2131PEX 600 ft-lbs ATEX/Hazardous Duty Pistol Grip Air Impact Wrench, 1/2” Square Drive, Pin Retainer. Actuation/Throttle Type/Switch Type: Feather-Touch Trigger Air Inlet: 1/4” NPT Air Pressure (PSI): 90 PSI Anvil Length:
The Ingersoll Rand 2131PEX 600 ft-lbs ATEX/Hazardous Duty Pistol Grip Air Impact Wrench, 1/2” Square Drive, Pin Retainer is specifically designed to meet ATEX Zone 1 or Zone 2 requirements. Reliable and durable from your first to your last job, this wrench will see you through. ATEX Marking: ATEX 2014/34/EU and Ex h IIA T6 Gb X ISO 80079-36 Certified
Thanks to its steel hammer case and composite housing, this wrench will endure anything, from repeated drops to harsh chemicals. It’ll never let you down. Bronze bushing reduces risk of sparks. Twin hammer mechanism ensures consistent power and balance. Pressure-fed mechanism lubrication ensures complete coverage throughout the tool. Feather-touch trigger allows precise delivery of pressure and speed. Composite housing is impact and chemical resistant to extend the life of the tool. ATEX Marking: ATEX 2014/34/EU and Ex h IIA T6 Gb X. ISO 80079-36 Certified. ATEX Rated.
Product Applications: Hazardous Environment, Heavy Industry, Oil & Gas, Foundry.
The Ingersoll Rand 2131PEX 600 ft-lbs ATEX/Hazardous Duty Pistol Grip Air Impact Wrench, 1/2” Square Drive, Pin Retainer is backed by a 1-year warranty for peace of mind.
| Part Number | 2131PEX |
|---|---|
| Actuation/Throttle/Switch | Feather-Touch Trigger |
| Air Inlet | 1/4'' NPT |
| Air Pressure (psi) | 90 PSI |
| Anvil Length | Standard |
| Average Air Consumption | 4.8 cfm |
| Blows Per Min | 1250 BPM |
| Color | Grey |
| Configuration/Handle Type | Pistol Grip |
| Drive Size | 1/2'' |
| Drive Type | Square |
| Duty Rating | Atex/Hazardous Duty |
| End Plates | Aluminum with Hard-coating |
| Exhaust Location | Bottom |
| Free Speed Sound Press/Power | 86.4 / 97.4 |
| Hammer Case | Steel |
| Handle Material | Composite |
| Impact Mechanism | Twin Hammer |
| Impacting Sound Press/Power | 90.4 / 101.4 |
| Max Bolt Diameter | 9/16'' |
| Max Free Speed | 10250RPM |
| Max Pressure | 6.2 bar |
| Max Torque | 600 ft-lbs / 7196 in-lbs / 813 Nm |
| Min. Hose Size | 3/8'' |
| Motor | Reverse Bias |
| Number of Power Settings | 4 |
| Power Source | Air Powered |
| Power to Weight Ratio | 122 ft-lbs/lbs |
| Product Height | 7.2'' / 183mm |
| Product Length | 7.3'' / 185mm |
| Product Weight | 4.9lbs / 2.22kg |
| Product Width | 2.7'' / 69mm |
| Recom. Forward Torque Range | 450 ft-lbs / 5399 in-lbs / 610 Nm |
| Retainer Type | Pin Detent |
| Side to Center Distance | 1.35'' / 34mm |
| Standards/Certifications | Atex 2014/34/Eu, Atex Ex H Iia T6 Gb X, Iso 80079-36 |
| Tool Type | Full-size |
| UPC | 6.63023E+11 |
| Vanes | 6 |
| Vibration Level (m/s2) | 8.31m/s2 |
| Warranty | 1-year |
The Ingersoll Rand 2131PEX 600 ft-lbs ATEX/Hazardous Duty Pistol Grip Air Impact Wrench, 1/2” Square Drive, Pin Retainer is specifically designed to meet ATEX Zone 1 or Zone 2 requirements. Reliable and durable from your first to your last job, this wrench will see you through. ATEX Marking: ATEX 2014/34/EU and Ex h IIA T6 Gb X ISO 80079-36 Certified
Thanks to its steel hammer case and composite housing, this wrench will endure anything, from repeated drops to harsh chemicals. It’ll never let you down. Bronze bushing reduces risk of sparks. Twin hammer mechanism ensures consistent power and balance. Pressure-fed mechanism lubrication ensures complete coverage throughout the tool. Feather-touch trigger allows precise delivery of pressure and speed. Composite housing is impact and chemical resistant to extend the life of the tool. ATEX Marking: ATEX 2014/34/EU and Ex h IIA T6 Gb X. ISO 80079-36 Certified. ATEX Rated.
Product Applications: Hazardous Environment, Heavy Industry, Oil & Gas, Foundry.
The Ingersoll Rand 2131PEX 600 ft-lbs ATEX/Hazardous Duty Pistol Grip Air Impact Wrench, 1/2” Square Drive, Pin Retainer is backed by a 1-year warranty for peace of mind.
| Part Number | 2131PEX |
|---|---|
| Actuation/Throttle/Switch | Feather-Touch Trigger |
| Air Inlet | 1/4'' NPT |
| Air Pressure (psi) | 90 PSI |
| Anvil Length | Standard |
| Average Air Consumption | 4.8 cfm |
| Blows Per Min | 1250 BPM |
| Color | Grey |
| Configuration/Handle Type | Pistol Grip |
| Drive Size | 1/2'' |
| Drive Type | Square |
| Duty Rating | Atex/Hazardous Duty |
| End Plates | Aluminum with Hard-coating |
| Exhaust Location | Bottom |
| Free Speed Sound Press/Power | 86.4 / 97.4 |
| Hammer Case | Steel |
| Handle Material | Composite |
| Impact Mechanism | Twin Hammer |
| Impacting Sound Press/Power | 90.4 / 101.4 |
| Max Bolt Diameter | 9/16'' |
| Max Free Speed | 10250RPM |
| Max Pressure | 6.2 bar |
| Max Torque | 600 ft-lbs / 7196 in-lbs / 813 Nm |
| Min. Hose Size | 3/8'' |
| Motor | Reverse Bias |
| Number of Power Settings | 4 |
| Power Source | Air Powered |
| Power to Weight Ratio | 122 ft-lbs/lbs |
| Product Height | 7.2'' / 183mm |
| Product Length | 7.3'' / 185mm |
| Product Weight | 4.9lbs / 2.22kg |
| Product Width | 2.7'' / 69mm |
| Recom. Forward Torque Range | 450 ft-lbs / 5399 in-lbs / 610 Nm |
| Retainer Type | Pin Detent |
| Side to Center Distance | 1.35'' / 34mm |
| Standards/Certifications | Atex 2014/34/Eu, Atex Ex H Iia T6 Gb X, Iso 80079-36 |
| Tool Type | Full-size |
| UPC | 6.63023E+11 |
| Vanes | 6 |
| Vibration Level (m/s2) | 8.31m/s2 |
| Warranty | 1-year |
