Ingersoll Rand 22KA1 Stub Taper Threaded Chuck Large Air Drill, 725RPM. Actuation/Throttle Type/Switch Type: Reversible, Roll Air Consumption (cfm): 55 cfm Air Consumption (l/min): 1558 l/min Air Inlet: 1/2” NPT Capacity in Steel Drilling: 9/16”
The Ingersoll Rand 22KA1 Stub Taper Threaded Chuck Large Air Drill, 725RPM is part of several series of large drills to meet your construction and industrial needs.
The Ingersoll Rand 22KA1 Stub Taper Threaded Chuck Large Air Drill, 725RPM is engineered to deliver professional performance, combining durability and ease of use for demanding applications. The 22 Series works best for general applications up to 7/8” (22mm) holes, while the 33, 44, and 551 Series are better suited for opening and closing large valves, or for drilling larger holes between 1 inch (25mm) and 3 inches (76mm). Side Exhaust: All the Ingersoll Rand large drills come with side exhaust to keep exhaust air pointed away from you and away from your work. Governed Motor: No matter which Ingersoll Rand large drill series youre interested in, you can expect a governed motor that regulates air intake to keep these drills working at the peak of their power curve. Lightweight: The 22 Series of large drills is strong but lightweight for increased ease of use. Balling bearing support for long life and efficient operation. Common applications for the Ingersoll Rand 22KA1 Stub Taper Threaded Chuck Large Air Drill, 725RPM: These air drills are designed for heavy duty drilling and reaming up to 7/8” (22mm) holes.
For peace of mind, the Ingersoll Rand 22KA1 Stub Taper Threaded Chuck Large Air Drill, 725RPM is backed by a 1-year warranty.
| Part Number | 22KA1 |
|---|---|
| Actuation/Throttle/Switch | Reversible, Roll |
| Air Consumption cfm | 55 cfm |
| Air consumption l/min | 1558 l/min |
| Air Inlet | 1/2'' NPT |
| Capacity in Steel Drilling | 9/16'' |
| Capacity in Steel Reaming | 7/16'' |
| Color | Beige |
| Configuration/Handle Type | T-Handle |
| Duty Rating | Super Duty |
| Exhaust Location | Side |
| Height Over Spindle | 17.63'' / 448mm |
| Length of Feed | 2.5'' / 64mm |
| Max Free Speed (rpm) | 725RPM |
| Max. Power | 1.75hp |
| Min. Hose Size | 3/4'' |
| Power Source | Air Powered |
| Product Weight | 15.25lbs / 6.92kg |
| Reversible | Reversible |
| Side to Center Distance (in) | 1.44'' / 37mm |
| Sound Pressure/Power Db(A) | 96.1 / 97.1 |
| Spindle Attachment | 5/64-1/2'' |
| Spindle Type | Stub Taper, Threaded Chuck |
| UPC | 6.63023E+11 |
| Vibration Level (m/s2) | < 2.5m/s2 |
| Warranty | 1-year |
