Ingersoll Rand 236 1/2” Square Drive Pistol Grip Air Impact Wrench. Actuation/Throttle Type/Switch Type: Trigger Air Consumption @ Load (cfm): 24 cfm Air Consumption @ Load (l/min): 680 l/min Air Inlet: 1/4” NPT Air Pressure (PSI): 90 PSI
The Ingersoll Rand 236 1/2” Square Drive Pistol Grip Air Impact Wrench will see you through every job that walks in the door if you work in vehicle repair. The 236 1/2” is strong and reliable, with a power regulator that allows for increased control from start to finish.
The 236 1/2” Impact Wrench will put in overtime on your toughest projects. Each part is tested for quality, so you can be sure itll deliver a high-performance output every time. This impact wrench comes with a finely tuned vane motor that pairs smoothly with the jumbo hammer impact mechanism for maximum power.
Optimized for vehicle repair or maintenance repair.
The Ingersoll Rand 236 1/2” Square Drive Pistol Grip Air Impact Wrench is backed by a 1-year warranty for peace of mind.
| Part Number | 236 |
|---|---|
| Actuation/Throttle/Switch | Trigger |
| Air Consumption @ Load (cfm) | 24 cfm |
| Air Consumption @ Load | 680 l/min |
| Air Inlet | 1/4'' NPT |
| Air Pressure (psi) | 90 PSI |
| Anvil Length | Standard |
| Average Air Consumption | 122 l/min |
| Blows Per Min | 1200 BPM |
| Color | Silver |
| Configuration/Handle Type | Pistol Grip |
| Drive Size | 1/2'' |
| Drive Type | Square |
| Duty Rating | General Duty |
| End Plates | Steel |
| Exhaust Location | Bottom |
| Free Speed Sound Press/Power | 90.3 / 101.3 |
| Hammer Case | Steel |
| Handle Material | Aluminum |
| Housing Material | Aluminum |
| Impact Mechanism | Jumbo Hammer |
| Max Bolt Diameter | 1/2'' |
| Max Free Speed | 7400RPM |
| Max Pressure | 6.2 bar |
| Max Torque | 450 ft-lbs / 5400 in-lbs / 610 Nm |
| Min. Hose Size | 3/8'' |
| Motor | Non-Biased |
| Number of Power Settings | 2 |
| Power Source | Air Powered |
| Power to Weight Ratio | 84.9 ft-lbs/lbs |
| Product Height | 7.2'' / 183mm |
| Product Length | 7'' / 178mm |
| Product Weight | 5.3lbs / 2.4kg |
| Product Width | 2.6'' / 66mm |
| Retainer Type | Friction Ring |
| Side to Center Distance | 1.3'' / 33mm |
| Standards/Certifications | Cagi B186, Iso 11148-6, Iso 15744, Iso 28927-2 |
| Tool Type | Full-size |
| UPC | 6.63023E+11 |
| Vanes | 6 |
| Vibration Level (m/s2) | 12m/s2 |
| Warranty | 1-year |
