Ingersoll Rand 2920B9 550 ft-lbs Super Duty D-Handle Air Impact Wrench, 3/4” Square Drive. Actuation/Throttle Type/Switch Type: Inside Trigger Air Inlet: 3/8” NPT Air Pressure (PSI): 90 PSI Anvil Length: Standard Average Air Consumption (cfm): 36 cfm
The Ingersoll Rand 2920B9 550 ft-lbs Super Duty D-Handle Air Impact Wrench, 3/4” Square Drive’s finely tuned motor and power regulator make this wrench one to beat. Reliable, durable and variable, it can get any job done.
This wrench can withstand drops or harsh conditions, thanks to its steel hammer case and metal housing. With a twin hammer impact mechanism that delivers even blows every time, and a power regulator that helps keep control, youll never doubt that this wrench will perform the way you want it to. Features pressure-fed lubrication and an integral muffler.
Optimized for general industrial use, rail, heavy machinery, oil and gas, and shipbuilding.
The Ingersoll Rand 2920B9 550 ft-lbs Super Duty D-Handle Air Impact Wrench, 3/4” Square Drive is backed by a 1-year warranty for peace of mind.
| Part Number | 2920B9 |
|---|---|
| Actuation/Throttle/Switch | Inside Trigger |
| Air Inlet | 3/8'' NPT |
| Air Pressure (psi) | 90 PSI |
| Anvil Length | Standard |
| Average Air Consumption cfm | 36 cfm |
| Average Air Consumption | 1020 l/min |
| Blows Per Min | 950 BPM |
| Color | Grey |
| Configuration/Handle Type | D-Handle |
| Drive Size | 3/4'' |
| Drive Type | Square |
| Duty Rating | Super Duty |
| End Plates | Cast Iron |
| Exhaust Location | Bottom |
| Free Speed Sound Press/Power | 88.8 / 99.8 |
| Hammer Case | Steel |
| Handle Material | Composite |
| Housing Material | Aluminum Core with Composite Sleeve |
| Impact Mechanism | Twin Hammer |
| Max Bolt Diameter | 1'' |
| Max Free Speed (rpm) | 5000RPM |
| Max Pressure | 6.2 bar |
| Max Torque | 550 ft-lbs / 6603 in-lbs / 746 Nm |
| Min. Hose Size | 1/2'' |
| Motor | Non-Biased |
| Number of Power Settings | Continuous |
| Power Source | Air Powered |
| Product Length | 17.5'' / 445mm |
| Product Weight | 23.69lbs / 10.75kg |
| Recom. Forward Torque Range | 150-500 ft-lbs / 1797-6001 in-lbs / 203-678 Nm |
| Recommended Reverse Torque | 150-500 ft-lbs / 203-678 Nm |
| Retainer Type | Thru-hole |
| Side to Center Distance | 1.31'' / 33mm |
| Speed Setting | Variable Speed |
| Standards/Certifications | CE |
| Tool Type | Full-size |
| UPC | 6.63023E+11 |
| Vanes | 6 |
| Vibration Level (m/s2) | 19.9m/s2 |
| Warranty | 1-year |
