Ingersoll Rand QA4AALD011NP25S06 115 in-lbs QA4 Series Stall Clutch Right Angle Air Nutrunner, 3/8” Square Drive. Actuation/Throttle Type/Switch Type: Lever Air Consumption (cfm): 27 cfm Air Inlet: 1/4” NPT Air Pressure (PSI): 90 PSI
The Ingersoll Rand QA4AALD011NP25S06 115 in-lbs QA4 Series Stall Clutch Right Angle Air Nutrunner, 3/8” Square Drive makes even the toughest jobs easier and more comfortable. With a reverse ring for your comfort and a 360-degree indexed angle head that provides maximum flexibility, hard-to-reach jobs are a breeze.
Ingersoll Rand QA4AALD011NP25S06 115 in-lbs QA4 Series Stall Clutch Right Angle Air Nutrunner, 3/8” Square Drive offers powerful performance up to 115 in-lbs of torque and speeds up to 1025RPM. Built to last and made to perform, the QA4 Series Angle Stalls motor runs to stall, ensuring consistent torque repeatability. With a lube-free motor, the QA4 Series is specially designed for easy upkeep, and is an economical alternative to shut-off tools. Recommended for soft pull applications not requiring critical torque control.
The Ingersoll Rand QA4AALD011NP25S06 115 in-lbs QA4 Series Stall Clutch Right Angle Air Nutrunner, 3/8” Square Drive is backed by a 1-year warranty for peace of mind.
| Part Number | QA4AALD011NP25S06 |
|---|---|
| Actuation/Throttle/Switch | Lever |
| Air Consumption cfm | 27 cfm |
| Air Inlet | 1/4'' NPT |
| Air Pressure (psi) | 90 PSI |
| Angle Head Height | 1.28'' |
| Clutch Type | Stall |
| Configuration/Handle Type | Right Angle |
| Drive Size | 3/8'' |
| Drive Type | Square |
| Exhaust Location | Rear |
| Fastener Size | M4 – M5 |
| Head Side to Center | 0.5'' |
| Housing Material | Steel |
| Max Free Speed (rpm) | 1025RPM |
| Max. Power | 0.5hp |
| Max Pressure | 6.2 bar |
| Max Torque | 9.6 ft-lbs / 115 in-lbs / 13.01 Nm |
| Min. Hose Size | 3/8'' |
| Mounting Type | Standard Gearcase |
| Power Source | Air Powered |
| Product Length | 11.1'' / 282mm |
| Product Weight | 2.47lbs / 1.12kg |
| Recom. Forward Torque Range | 3.7-8.5 ft-lbs / 44-102 in-lbs / 5 – 11.5 Nm |
| Reversible | Reversible |
| Sound Pressure/Power Db(A) | 79.3 |
| UPC | 6.63023E+11 |
| Vibration Level (m/s2) | < 2.5m/s2 |
| Warranty | 1-year |
The Ingersoll Rand QA4AALD011NP25S06 115 in-lbs QA4 Series Stall Clutch Right Angle Air Nutrunner, 3/8” Square Drive makes even the toughest jobs easier and more comfortable. With a reverse ring for your comfort and a 360-degree indexed angle head that provides maximum flexibility, hard-to-reach jobs are a breeze.
Ingersoll Rand QA4AALD011NP25S06 115 in-lbs QA4 Series Stall Clutch Right Angle Air Nutrunner, 3/8” Square Drive offers powerful performance up to 115 in-lbs of torque and speeds up to 1025RPM. Built to last and made to perform, the QA4 Series Angle Stalls motor runs to stall, ensuring consistent torque repeatability. With a lube-free motor, the QA4 Series is specially designed for easy upkeep, and is an economical alternative to shut-off tools. Recommended for soft pull applications not requiring critical torque control.
The Ingersoll Rand QA4AALD011NP25S06 115 in-lbs QA4 Series Stall Clutch Right Angle Air Nutrunner, 3/8” Square Drive is backed by a 1-year warranty for peace of mind.
| Part Number | QA4AALD011NP25S06 |
|---|---|
| Actuation/Throttle/Switch | Lever |
| Air Consumption cfm | 27 cfm |
| Air Inlet | 1/4'' NPT |
| Air Pressure (psi) | 90 PSI |
| Angle Head Height | 1.28'' |
| Clutch Type | Stall |
| Configuration/Handle Type | Right Angle |
| Drive Size | 3/8'' |
| Drive Type | Square |
| Exhaust Location | Rear |
| Fastener Size | M4 – M5 |
| Head Side to Center | 0.5'' |
| Housing Material | Steel |
| Max Free Speed (rpm) | 1025RPM |
| Max. Power | 0.5hp |
| Max Pressure | 6.2 bar |
| Max Torque | 9.6 ft-lbs / 115 in-lbs / 13.01 Nm |
| Min. Hose Size | 3/8'' |
| Mounting Type | Standard Gearcase |
| Power Source | Air Powered |
| Product Length | 11.1'' / 282mm |
| Product Weight | 2.47lbs / 1.12kg |
| Recom. Forward Torque Range | 3.7-8.5 ft-lbs / 44-102 in-lbs / 5 – 11.5 Nm |
| Reversible | Reversible |
| Sound Pressure/Power Db(A) | 79.3 |
| UPC | 6.63023E+11 |
| Vibration Level (m/s2) | < 2.5m/s2 |
| Warranty | 1-year |
