Ingersoll Rand W3151 IQV20 Cordless Compact Impact Wrench Bare Tool, 1/2” Square Drive. Actuation/Throttle Type/Switch Type: Trigger Anvil Length: Standard Blows per Min: 4200 BPM (BL2022) Built-in Light: Yes Color: Grey
The Ingersoll Rand W3151 IQV20 Cordless Compact Impact Wrench Bare Tool, 1/2” Square Drive stands out as a reliable solution tailored for professional demands, combining power with user-focused design. One of the key strengths is the powerful brushless motor that delivers up to 450 ft-lbs. of breakaway torque. Ingersoll Rand W3151 IQV20 Cordless Compact Impact Wrench Bare Tool, 1/2” Square Drive is compact at 5.3” tip-to-tail length that enables you to enclosed spaces and features 3 Speed modes with variable speed trigger to fine-tune for application.
Ingersoll Rand W3151 IQV20 Cordless Compact Impact Wrench Bare Tool, 1/2” Square Drive features an impact-resistant design with comfortable over molded handle grip and is lightweight at 2.3lbs providing the user with excellent control and maneuverability of tool. Clear visibility comes from the 360° shadowless LED light ring to fully eliminate shadows. Ingersoll Rand W3151 IQV20 Cordless Compact Impact Wrench Bare Tool, 1/2” Square Drive works with all IQV® 20 batteries. This configuration includes Bare tool only; batteries and charger sold separately. In practical use, the Ingersoll Rand W3151 IQV20 Cordless Compact Impact Wrench Bare Tool, 1/2” Square Drive excels in applications such as removing and installing threaded fasteners.
| Part Number | W3151 |
|---|---|
| Actuation/Throttle/Switch | Trigger |
| Anvil Length | Standard |
| Blows Per Min | 4200 BPM (BL2022) |
| Built-in light | Yes |
| Color | Grey |
| Configuration/Handle Type | Pistol Grip |
| Country of Origin | China |
| Drive Size | 1/2'' |
| Drive Type | Square |
| Duty Rating | General Duty |
| ECCN | EAR99 |
| Forward Torque Setting 1 | 100 ft-lbs / 1195 in-lbs / 135 Nm |
| Forward Torque Setting 2 | 181 ft-lbs / 2168 in-lbs / 245 Nm |
| Forward Torque Setting 3 | 321 ft-lbs / 3850 in-lbs / 435 Nm |
| Hammer Case | Metal |
| Housing Material | Impact and Chemical-Resistant Composite Housing |
| HTS (Harmonized Tariff Code) | 8467290040 |
| Impact Mechanism | Ball and Cam |
| Lumens | 34 |
| Max Free Speed | 2800RPM |
| Max Torque | 321 ft-lbs / 3850 in-lbs / 435 Nm |
| Motor | Brushless Motor |
| Number of Batteries Required | 1 |
| Number of Power Settings | 3 |
| Nut-busting/Breakaway Torque | 450 ft-lbs / 5400 in-lbs / 610 Nm |
| Power Source | Battery Powered |
| Power to Weight Ratio | 119.4 ft-lbs/lbs (BL2022) |
| Product Height | 8.3'' / 211mm |
| Product Length | 5.3'' / 135mm |
| Product Weight | 1.03 kg / 2.26 lbs |
| Product Weight with Battery | 1.4 kg (BL2012), 1.7 kg (BL2022) / 3.19 lbs (BL2012), 3.77 lbs (BL2022) |
| Product Width | 2.56'' / 65mm |
| Recom. Forward Torque Range | 321 ft-lbs / 3850 in-lbs / 435 Nm |
| Retainer Type | Friction Ring |
| RPM Setting 1 | 725RPM |
| RPM Setting 2 | 1600RPM |
| Side to Center Distance | 1.28'' / 33mm |
| Sound Pressure/Power Db(A) | 90 / 101 |
| Speed Setting | Variable Speed |
| Standards/Certifications | EN/IEC 62841-2-2, UL/EN/IEC 62841-1 |
| TAA Compliant | No |
| Tool Type | Compact, Mid-Torque |
| UPC | 6.63023E+11 |
| Vibration Level (m/s2) | 18.1 |
| Vibra. Uncertainy K* (m/s2) | 5.8 |
| Voltage DC | 20 |
| Wireless Tool Tracking | No Wireless Functionality |
| Shipping Height | 3.38'' / 86mm |
| Shipping Length | 11.63'' / 295mm |
| Shipping Weight | 1.27kg / 2.8lbs |
| Shipping Width | 7.75'' / 197mm |
| Strat Code | STS-F |
| UNSPSC | 27112713 |
