Weller Digital Compressed Air Hot Air Station. Dimensions: 4.5” x 5.9” x 3.6” Voltage: 120V (input); 24V (output) Temperature Range: 150F – 999F (50C – 550C) Air Flow Volume: 1 l/min. 6 l/min Temp Accuracy: +/- 54F (+/- 30C)
Weller WAD101N Digital Compressed Air Hot Air Station features a powerful 100-watt HAP1 pencil that precisely delivers hot air to small SMT parts which reduces the risk of damage to adjacent components and in order to provide exeptional control there is a finger-activated hot air switch on the pencil. The Weller WAD101N Digital Compressed Air Hot Air Station’s digital temperature control has easy-to-read LED display for fast and accurate temperature set, the optional WCB1 programming module provides temperature lock-out for process control, temperature set-back for extended tip life, and F to C conversion.
Dimensions | 10.0'' x 11.0'' x 2.75'' |
---|---|
Heating Plate Dimension | 6.0'' x 8.75'' |
Power Supply | 120V/ 50/60Hz |
Power | 850 W |
Temperature Range | 150F – 570F(50C – 300C) |
UPC | 037103194367 |
Dimensions | 10.0'' x 11.0'' x 2.75'' |
---|---|
Heating Plate Dimension | 6.0'' x 8.75'' |
Power Supply | 120V/ 50/60Hz |
Power | 850 W |
Temperature Range | 150F – 570F(50C – 300C) |
UPC | 037103194367 |
